Cores Onyx Carbon/True Blue

Quadro OCLV Mountain Carbon main Quadro / swingarm, Carbon Armor, ABP Convert, Flow Mold Carbon swing link, G2 Geometry, E2 tapered head tube, replaceable derailleur hanger, 110mm travel

Suspensão Fox Factory Series 32 Float 29 FIT RLC, air spring, lockout, rebound, compression, custom G2 Geometry, E2 tapered steerer, 15QR thru axle, 100mm travel, tuned by Trek in California

Amortecedor Fox Performance Series Float RP-23 Adaptive Logic w/Kashima coat, Boost Valve, 3-position ProPedal, rebound, 7.75x1.75, tuned by Trek in California

Tamanhos 15.5, 17.5, 19, 21, 23

Rodas Bontrager Race Lite TLR Disc 29 wheel system, 15mm FCC front hub, 142x12mm rear hub, 28 hole, Tubeless Ready

Pneus Bontrager 29-1 Team, 29x2.2

Manípulos de mudança Shimano Deore XT M780, 10 speed

Desviador da Frente Shimano Deore XT, direct mount

Desviador de trás Shimano Deore XT M780 Shadow

Pedaleiro Shimano Deore XT M785, 38/26

Cassette Shimano Deore XT 11-36, 10 speed

Pedais n/a

Selim Bontrager Evoke 3, titanium rails

Espigão de selim Bontrager Race X Lite, 31.6mm, 5mm offset

Guiador Bontrager Race X Lite Carbon Big Sweep, 12 degree sweep

Avanço Bontrager Race X Lite, 31.8mm

Caixa de direcção FSA NO.57, E2, ACB sealed bearings

Travões Shimano Deore XT hydraulic disc brakes

Punhos Bontrager Race Lite, lock-on

Extras Trek fork / shock sag meter, Bontrager shock pump
