Cores Gloss PlatinumSignature Green

Quadro Alpha Gold Aluminum, butted / hydroformed tubing, cold-forged dropouts / bottom bracket, G2 Geometry

Suspensão SR Suntour XCM w/mechanical lockout, preload, custom G2 Geometry, 51mm offset, 100mm travel

Tamanhos 15.5, 17.5, 19, 21, 23

Rodas Formula DC20 alloy front hub, Shimano M475 alloy rear hub, Bontrager AT-850 disc 29 32-hole rims

Pneus Bontrager 29-2, 29x2.1

Manípulos de mudança SRAM X4, 8 speed

Desviador da Frente Shimano Altus

Desviador de trás SRAM X4

Pedaleiro Shimano Altus M311, 42/32/22

Cassette Shimano HG31 11-34, 8 speed

Pedais Wellgo ATB, boron axle, alloy cage

Selim Bontrager Evoke 1

Espigão de selim Bontrager SSR, 27.2mm, 20mm offset

Guiador Bontrager Low Riser, 25.4mm, 5mm rise, 9 degree sweep

Avanço Bontrager Approved, 25.4mm

Caixa de direcção 1-1/8 threadless, semi-integrated, semi-cartridge bearings

Travões Tektro Novela mechanical disc brakes, 6-bolt, 160mm rotors

Punhos Bontrager Race Lite
