Cores Metallic Black

Quadro Alpha Platinum Aluminum, butted / hydroformed tubing, E2 tapered head tube, press fit bottom bracket, cold-forged dropouts, G2 29 geometry

Suspensão Fox Evolution Series 32 Float 29 RL, air spring, lockout, rebound, custom G2 Geometry, 51mm offset crown, 100mm travel

Tamanhos 15.5, 17.5, 19, 21, 23

Rodas Bontrager 28-hole FCC alloy front hub, Shimano M525 32-hole alloy rear hub, Bontrager Mustang Disc 29 rims, Tubeless Ready

Pneus Bontrager 29-1 Expert, 29x2.2

Manípulos de mudança Shimano Deore M591, 10 speed

Desviador da Frente Shimano Deore

Desviador de trás Shimano Deore XT M780 Shadow

Pedaleiro Shimano M552, 42/32/24

Cassette Shimano HG62-10 11-36, 10 speed

Pedais n/a

Selim Bontrager Evoke 2, chromoly rails

Espigão de selim Bontrager Rhythm Elite, 27.2mm, zero offset

Guiador Bontrager Low Riser, 31.8mm, 5mm rise, 9 degree sweep

Avanço Bontrager Race Lite, 31.8mm

Caixa de direcção FSA NO.57, E2, ACB sealed bearings

Travões Avid Elixir 3 hydraulic disc brakes

Punhos Bontrager Race Lite

Extras Trek fork sag meter
