Cores Crystal Pearl White

Quadro Alpha Platinum Aluminum, butted / hydroformed tubing, E2 tapered head tube, press fit bottom bracket, cold-forged dropouts, G2 29 geometry

Suspensão Fox Evolution Series 32 Float 29 RL, air spring, lockout, rebound, custom G2 Geometry, 51mm offset crown, E2 tapered steerer, 100mm travel

Tamanhos 15.5, 17.5, 19, 21, 23

Rodas Bontrager 28-hole FCC alloy front hub, Shimano M525 SL 32-hole alloy rear hub, Bontrager Mustang Disc 29 rims, Tubeless Ready

Pneus Bontrager 29-1 Expert, 29x2.2

Manípulos de mudança Shimano SLX M660-10, 10 speed

Desviador da Frente Shimano SLX

Desviador de trás Shimano Deore XT M780 Shadow

Pedaleiro Custom Shimano M772, 42/32/24

Cassette Shimano HG62-10 11-36, 10 speed

Pedais n/a

Selim Bontrager Evoke 2, chromoly rails

Espigão de selim Bontrager Rhythm Elite, 27.2mm, zero offset

Guiador Bontrager Race Lite Low Riser, 31.8mm, 5mm rise, 9 degree sweep

Avanço Bontrager Race X Lite, 31.8mm

Caixa de direcção FSA NO.57, E2, ACB sealed bearings

Travões Shimano M666 SLX hydraulic disc brakes

Punhos Bontrager Race Lite, lock-on

Extras Trek fork sag meter
