Cores Paramount Grey/Onyx Carbon

Quadro OCLV Mountain Carbon w/BB90 bottom bracket, Drop In headset bearings

Suspensão Fox Evolution Series 32 Float RL, air spring, lockout, rebound, 100mm travel

Tamanhos 15.5, 17.5, 18.5, 19.5, 21.5

Rodas Shimano Deore XT M785 alloy hubs, Bontrager Mustang Disc 32-hole rims, Tubeless Ready

Pneus Bontrager XR1 Expert, 26x2.2

Manípulos de mudança Shimano SLX M660-10, 10 speed

Desviador da Frente Shimano Deore

Desviador de trás Shimano Deore XT M780 Shadow

Pedaleiro Shimano Deore XT M780, 42/32/24

Cassette Shimano SLX HG81-10 11-36, 10 speed

Pedais n/a

Selim Bontrager Evoke 2, chromoly rails

Espigão de selim Bontrager Rhythm Elite, 31.6mm, zero offset

Guiador Bontrager Race Lite Low Riser, 31.8mm, 15mm rise, 9 degree sweep

Avanço Bontrager Race Lite, 31.8mm

Caixa de direcção Cane Creek IS-3, alloy cartridge, 1-1/8

Travões Shimano SLX M666 hydraulic disc brakes

Punhos Bontrager Race Lite, lock-on

Extras Trek fork sag meter
