Cores Raw Tint Dark

Quadro Alpha Platinum Aluminum w/ABP Convert, Full Floater, E2 tapered head tube, AngleSet compatible, internal control routing, alloy EVO Link, Mino Link, replaceable derailleur hanger, 210mm travel

Suspensão Fox Factory Series 40 Fit RC2 w/steel coil spring (S, M blue, L, XL green), hi/lo speed compression, rebound, 1-1/8 steerer, 20mm thru axle, 203mm travel

Amortecedor Fox DHX RC-2 w/externally adjustable velocity sensitive damping, bottom-out force adjust and bottom-out progressiveness, external rebound, 8.75x2.75 (S 400lb, M 450lb, L 500lb, XL 500lb spring), tuned by Trek in California

Tamanhos S, M, L, XL

Rodas Bontrager Cousin Earl TLR Disc wheel system, 20mm front hub, 157x12mm rear hub, 32 hole, Tubeless Ready

Pneus Bontrager G4 Team, 26x2.35

Manípulos de mudança SRAM X9, 10 speed

Desviador da Frente n/a

Desviador de trás SRAM X0

Pedaleiro SRAM Descendant DH, 38T

Cassette SRAM PG-1050 11-26, 10 speed

Pedais Wellgo MG-1

Selim Bontrager Evoke 2, chromoly rails

Espigão de selim Bontrager Rhythm Elite, 31.6mm, zero offset

Guiador Bontrager Rhythm Elite, 31.8mm, 15mm rise, 9 degree sweep

Avanço Truvativ Holzfeller, 31.8mm, direct connect

Caixa de direcção Cane Creek Angleset, E2

Travões Avid Elixir 9 hydraulic disk brakes

Punhos Bontrager Rhythm, dual lock-on

Extras Trek fork sag meter, Aluminium Armor
