Cores Carbon Smoke

Quadro OCLV Mountain Carbon w/InTension main Quadro / seatstay, alloy chainstay, Carbon Armor, ABP DH, Full Floater, E2 tapered head tube, AngleSet compatible, internal control routing, HexMC carbon EVO Link, Mino Link, MicroTruss, replaceable derailleur hanger, 210mm travel

Suspensão Fox Factory Series 40 Fit RC2 Hybrid Air w/Ti coil spring, Kashima coat, hi/lo speed compression, rebound, 1-1/8 steerer, 20mm thru axle, 203mm travel

Amortecedor Fox DHX RC-4 w/externally adjustable velocity sensitive damping, bottom-out force adjust and bottom-out progressiveness, external rebound, 8.75x2.75 (S 400lb, M 450lb, L 500lb, XL 500lb spring), tuned by Trek in California

Tamanhos S, M, L, XL

Rodas DT Swiss 240s, 20mm front hub, 157x12mm rear hub, DT Swiss FR 600 32-hole rims

Pneus Bontrager G4 Team, 26x2.35

Manípulos de mudança SRAM X0, 10 speed

Desviador da Frente n/a

Desviador de trás SRAM X0

Pedaleiro SRAM X0 DH Carbon, 38T

Cassette SRAM PG-1070 11-26, 10 speed

Pedais Wellgo MG-1

Selim Bontrager Evoke 4, titanium rails

Espigão de selim Bontrager Rhythm Elite, 31.6mm, zero offset

Guiador Bontrager Rhythm Pro Carbon, 31.8mm, 15mm rise, 9 degree sweep

Avanço Truvativ Holzfeller, 31.8mm, direct connect

Caixa de direcção Cane Creek Angleset, E2

Travões Avid Elixir XO hydraulic disc brakes

Punhos Bontrager Rhythm, dual lock-on
