Cores Crystal Pearl WhiteMatte Black/True Blue

Quadro Alpha Platinum Aluminum w/ABP Convert, Full Floater, E2 tapered head tube, internal front derailleur cable routing, magnesium EVO Link, replaceable derailleur hanger, 120mm travel

Suspensão Fox Evolution Series 32 Float RL, air spring, lockout, rebound, 15QR thru axle, 120mm travel

Amortecedor Fox Performance Series Float RP-2 w/DRCV, ProPedal, rebound, 7.25x2.0, tuned by Trek in California

Tamanhos 15.5, 17.5, 18.5, 19.5, 21.5

Rodas Formula DC51 15mm alloy front hub, Shimano M525 alloy rear hub, Bontrager Duster Disc 32-hole rims, Tubeless Ready

Pneus Bontrager XR4 Expert, 26x2.2

Manípulos de mudança Shimano Deore M591, 10 speed

Desviador da Frente Shimano Deore

Desviador de trás Shimano SLX M663 Shadow

Pedaleiro Shimano M552, 42/32/24

Cassette Shimano HG62-10 11-36, 10 speed

Pedais n/a

Selim Bontrager Evoke 2, chromoly rails

Espigão de selim Bontrager SSR, 31.6mm, 20mm offset

Guiador Bontrager Low Riser, 31.8mm, 15mm rise, 9 degree sweep

Avanço Bontrager Race Lite, 31.8mm

Caixa de direcção FSA NO.57E, E2, ACB sealed bearings

Travões Avid Elixir 3 hydraulic disc brakes

Punhos Bontrager Race Lite, single lock-on

Extras Trek fork / shock sag meter, Bontrager shock pump
