Cores Matte TiMatte Black

Quadro Alpha Platinum Aluminum w/ABP Convert, Full Floater, E2 tapered head tube, internal front derailleur cable routing, magnesium EVO Link, replaceable derailleur hanger, 120mm travel

Suspensão Fox 32 Float RL, Trek DRCV air spring, lockout, rebound, E2 tapered steerer, 15QR thru axle, 120mm travel, tuned by Trek in California

Amortecedor Fox Performance Series Float RP-2 w/DRCV, ProPedal, rebound, 7.25x2.0, tuned by Trek in California

Tamanhos 15.5, 17.5, 18.5, 19.5, 21.5

Rodas Bontrager Rhythm Comp TLR Disc wheel system, 15mm front hub, 142x12mm rear hub, 28 hole, Tubeless Ready

Pneus Bontrager XR4 Expert, 26x2.2

Manípulos de mudança Shimano SLX M660-10, 10 speed

Desviador da Frente Shimano SLX

Desviador de trás Shimano Deore XT M780 Shadow

Pedaleiro Shimano Deore XT M780, 42/32/24

Cassette Shimano HG62-10 11-36, 10 speed

Pedais n/a

Selim Bontrager Evoke 2, chromoly rails

Espigão de selim Bontrager Rhythm Elite, 31.6mm, zero offset

Guiador Bontrager Race Lite Low Riser, 31.8mm, 15mm rise, 9 degree sweep

Avanço Bontrager Race Lite, 31.8mm

Caixa de direcção FSA NO.57E, E2, ACB sealed bearings

Travões Shimano SLX M666 hydraulic disc brakes

Punhos Bontrager Race Lite, single lock-on

Extras Trek fork / shock sag meter, Bontrager shock pump
