Cores Raw Tint Dark

Quadro Alpha Platinum Aluminum w/ABP Convert, Full Floater, E2 tapered head tube, internal front derailleur cable routing, magnesium EVO Link, replaceable derailleur hanger, 120mm travel

Suspensão Fox 32 Float FIT RLC, Trek DRCV air spring, Kashima coat, compression, lockout, rebound, E2 tapered steerer, 15QR thru axle, 120mm travel, tuned by Trek in California

Amortecedor Fox Performance Series Float RP-3 w/DRCV, Boost Valve, 3-position Climb-Ride-Descend ProPedal, rebound, 7.25x2.0, tuned by Trek in California

Tamanhos 15.5, 17.5, 18.5, 19.5, 21.5

Rodas Bontrager Rhythm Elite TLR Disc wheel system, 15mm front hub, 142x12mm rear hub, 28 hole, Tubeless Ready

Pneus Bontrager XR4 Team, 26x2.2

Manípulos de mudança Shimano Deore XT M780, 10 speed

Desviador da Frente Shimano Deore XT

Desviador de trás Shimano XTR M980 Shadow

Pedaleiro Shimano Deore XT M780, 42/32/24

Cassette Shimano Deore XT M771-10 11-36, 10 speed

Pedais n/a

Selim Bontrager Evoke 2, chromoly rails

Espigão de selim Bontrager Rhythm Elite, 31.6mm, zero offset

Guiador Bontrager Race Lite Low Riser, 31.8mm, 15mm rise, 9 degree sweep

Avanço Bontrager Race Lite, 31.8mm

Caixa de direcção FSA NO.57E, E2, ACB sealed bearings

Travões Shimano Deore XT M785 hydraulic disc brakes

Punhos Bontrager Race Lite, single lock-on

Extras Trek fork / shock sag meter, Bontrager shock pump
