Cores Matte Onyx Carbon/Red

Quadro OCLV Mountain Carbon main Quadro, seatstay / chainstay, Carbon Armor, ABP Convert, Full Floater, E2 tapered head tube, front derailleur internal cable routing, magnesium EVO Link, replaceable derailleur hanger, 120mm travel

Suspensão Fox 32 Float FIT RLC, Trek DRCV air spring, Kashima coat, compression, lockout, rebound, E2 tapered steerer, 15QR thru axle, 120mm travel, tuned by Trek in California

Amortecedor Fox Float RP-3 w/DRCV, Kashima coat, Boost Valve, 3-position Climb-Ride-Descend ProPedal, rebound, 7.25x2.0, tuned by Trek in California

Tamanhos 15.5, 17.5, 18.5, 19.5, 21.5

Rodas DT Swiss XM 1550 Tricon, 15mm front hub, 142x12mm rear hub, 24-hole, center lock, tubeless rims (no spoke holes)

Pneus Bontrager XR4 Team, 26x2.2

Manípulos de mudança SRAM XX, 10 speed

Desviador da Frente SRAM XX

Desviador de trás SRAM XX

Pedaleiro SRAM XX, 39/26

Cassette SRAM XX 11-36, 10 speed

Pedais n/a

Selim Bontrager Evoke 4, titanium rails

Espigão de selim Bontrager Race XXX Lite, 31.6mm

Guiador Bontrager Race X Lite Carbon Low Riser, 31.8mm, 15mm rise, 9 degree sweep

Avanço Bontrager Race XXX Lite, 31.8mm

Caixa de direcção Cane Creek IS-3, E2, alloy cartridge

Travões Avid XX hydraulic disc brakes

Punhos Bontrager Race Lite, single lock-on

Extras Trek fork / shock sag meter, Bontrager shock pump
