Cores Onyx Carbon

Quadro OCLV Mountain Carbon main Quadro, seatstay / chainstay, Carbon Armor, ABP Convert, Full Floater, E2 tapered head tube, front derailleur internal cable routing, stealth seatpost routing, magnesium EVO Link, Mino Link, replaceable derailleur hanger, 150mm travel

Suspensão Fox 32 Float FIT RLC, Trek DRCV air spring, Kashima coat, compression, lockout, rebound, E2 tapered steerer, 15QR thru axle, 150mm travel, tuned by Trek in California

Amortecedor Fox Float RP-3 w/DRCV, Kashima coat, Boost Valve, 3-position Climb-Ride-Descend ProPedal, rebound, 7.75x2.25, tuned by Trek in California

Tamanhos 15.5, 17.5, 18.5, 19.5, 21.5

Rodas DT Swiss XM 1550 Tricon, 15mm front hub, 142x12mm rear hub, 24-hole, center lock, tubeless rims

Pneus Bontrager XR4 Team, 26x2.35

Manípulos de mudança SRAM XX, 10 speed

Desviador da Frente SRAM X0, direct mount

Desviador de trás SRAM XX

Pedaleiro SRAM XX, 39/26

Cassette SRAM XX 11-36, 10 speed

Pedais n/a

Selim Bontrager Evoke RXL

Espigão de selim RockShox Reverb Stealth, 31.6mm, zero offset

Guiador Bontrager Race X Lite Carbon Low Riser, 31.8mm, 15mm rise, 9 degree sweep

Avanço Bontrager Rhythm Pro, 31.8mm

Caixa de direcção Cane Creek IS3, E2

Travões Avid XX hydraulic disc brakes

Punhos Bontrager Rhythm, dual lock-on

Extras Trek fork / shock sag meter, Bontrager shock pump
