Cores Gloss Black/Paramount Grey

Quadro Alpha Silver Aluminum w/ABP Race, Full Floater, magnesium EVO Link, replaceable derailleur hanger, 100mm travel

Suspensão Fox Evolution Series 32 Float RL, air spring, remote lockout, rebound, 15QR thru axle, 100mm travel

Amortecedor Fox Performance Series Float RP-2 BSD, ProPedal, rebound, 6.5x1.5, Tuned by Trek in California

Tamanhos 15.5, 17.5, 18.5, 19.5, 21.5

Rodas Bontrager Race Lite TLR Disc wheel system, 15mm front hub, 135x5mm rear hub, 28 hole, center lock, Tubeless Ready

Pneus Bontrager XR1 Expert, 26x2.2

Manípulos de mudança Shimano SLX M660-10, 10 speed

Desviador da Frente Shimano SLX

Desviador de trás Shimano Deore XT M780 Shadow

Pedaleiro Custom Shimano M772, 42/32/24

Cassette Shimano HG62-10 11-36, 10 speed

Pedais n/a

Selim Bontrager Evoke 2, chromoly rails

Espigão de selim Bontrager Rhythm Elite, 31.6mm, zero offset

Guiador Bontrager Race Lite Low Riser, 31.8mm, 15mm rise, 9 degree sweep

Avanço Bontrager Race Lite, 31.8mm

Caixa de direcção FSA Orbit Z, 1-1/8 semi-integrated, sealed

Travões Shimano SLX M666 hydraulic disc brakes

Punhos Bontrager Race Lite

Extras Trek fork / shock sag meter, Bontrager shock pump
